Symmetry thermo

Run virtually any processing application throughout your well's life cycle

Symmetry
minus

An extensively validated thermodynamics library with almost 20 years of program refinement

Symmetry Thermo is an accurate predictor of phase equilibria and physical properties for a variety of mixtures, which has been used for almost two decades by the oil and gas industry.

Get world-class simulation software for a variety of processing applications

Run virtually any processing application throughout your well's life cycle

The result of our work is a thermo-physical property calculator with the versatility to monitor the performance of an engine or natural gas well, optimize your natural gas compressors, and improve the safety of the relief valves.

Symmetry Thermo powers the Symmetry process simulation software and many other custom software applications. Its unique programming interface gives it the flexibility to embed in any process simulation software or engineering application.

Tried, tested, and true

Relentless testing using experimental data collected and evaluated at the Thermodynamics Research Centre in Boulder, Colorado has made Symmetry Thermo the most accurate predictor of phase equilibria and physical properties for many processes used in the industry.

Symmetry Thermo is capable of accurately predicting the behaviour of complex combinations of chemicals. With more than 80 thermodynamic property packages, Symmetry Thermo can model most process systems.

Multiphase flash system

The multiphase flash system Symmetry Thermo has a robust material balance and phase stability algorithm.

It calculates the number of phases in your process as well as the composition, amount, and physical properties of the materials in each phase at thermodynamic equilibrium.

Our flash system reliably performs the basic calculations for steady-state process simulators such as the Symmetry process platform and dynamic process simulators such as Symmetry software and IDEAS.

Beyond process simulation

Symmetry Thermo is continuously validated, giving it the capability to model a wide variety of systems out of the box. It is also configurable and able to handle different specifications for flash calculations.

These features make it the property package system of choice for designing relief valves, compressors, and online monitoring systems.

Build accurate virtual processing models every time

The Thermodynamics Research Centre (TRC), a part of the National Institute of Standards and Technology (NIST) focuses its work exclusively on collecting and evaluating the physical properties of fluids.

Symmetry Thermo

Ensure accurate and reliable thermodynamics properties every time

Symmetry Thermo is a set of software components used for the calculation of thermo-physical properties and flash calculations. It's a carefully crafted set of application programming interfaces that are used to power any application that can benefit from high quality physical properties.

Symmetry Thermo includes interfaces for:

  • EXCEL
  • Visual Basic
  • Delphi
  • Visual C++
  • C
  • C++
  • FORTRAN

If you know how to use a spreadsheet, you can use Symmetry Thermo.

Symmetry Thermo also ensures reliable and accurate process simulation modeling in Symmetry process simulation software.

Symmetry Thermo provides you with a complete set of physical and thermodynamic properties for pure components and mixtures over a wide range of pressures, temperatures, compositions, and phases.

Also included is a comprehensive pure component database with nearly 5,500 pure components, with more than 100 physical properties per component. These include important properties for environmental applications, such as maximum exposure limits, adsorption capacity in activated carbon, and solubility in water.

Accessing Symmetry Thermo

Symmetry Thermo may be executed from Excel via a VBA interface or a user’s own calculation program as a callable DLL or within Symmetry software. Symmetry Thermo is being used as an operator advisory tool. Symmetry Thermo is also CAPE-OPEN enabled and can thus be interfaced to software at this interface level.

Comprehensive estimation

Missing pure component physical properties are automatically estimated using a recommended set of models. Missing interaction parameters for activity coefficient models are automatically estimated using UNIQUAC functional group activity coefficients (UNIFAC). And all estimated interaction parameters are documented and can be user-inspected.
