N-Series REDA ESP Pumps

Efficient, reliable pumps for casing sizes 11 3/4 in and larger

AGH Gas Handling
Contact Us Related Resources
Target production rate: 24,000 to 64,000 bbl/d at 60 Hz [3,180 to 8,480 m3/d at 50 Hz]
Casing size: 11 3/4 in and larger
Abrasion-resistant bearing configuration for reliability in sandy wells and other demanding applications
Corrosion-resistant coatings and stainless steel construction for wells with H2S, CO2, and other corrosive conditions

Reduce power consumption with high-efficiency pump design

N-Series REDA ESP pumps are high-efficiency, multistage centrifugal pumps used in oil and other industry  applications.

Each pump comprises a rotating impeller and a stationary diffuser that are designed to deliver hydraulic efficiency and optimal lift performance.

Bearing configuration, high-strength shafts, and factory shimming improve reliability and extend system run life in challenging applications.

Cut workover costs by accelerating ESP installation

Factory shimming enables precise shaft setting to match REDA Maximus install-ready ESP motors and protectors and reduce installation time by at least 60%.

In addition to typical oil, water, and brine production, they are used for booster service, ballast transfer, waterfloods, direct injection, cavern storage, mine dewatering, fire protection, irrigation, and commercial water systems.

Photograph of ESP pumps awaiting installation at the factory.
View All

Case Study AngloGold Ashanti Increases Mine Dewatering Performance While Cutting Costs and Energy Consumption

Grid-powered Sensia variable frequency drive and encased REDA pump improve efficiency vs. diesel-driven, vacuum-primed heavy-duty mine dewatering pumps.
