MagniSphere

MagniSphere™ high-definition NMR logging-while-drilling service delivers real-time, lithology-independent formation evaluation while drilling, enabling confident reservoir characterization in complex environments. The service provides direct insight into pore structure, fluid distribution, and producibility in real time. MagniSphere service acquires high-quality NMR measurements under dynamic drilling conditions, including simultaneous T₁ and T₂ relaxation information to deliver accurate porosity, permeability indicators, bound fluid volume, free fluid volume, and rock typing in both clastic and carbonate reservoirs. High-definition relaxation maps improve fluid identification, saturation evaluation, and reservoir quality assessment in heterogeneous, laminated, and thin-bed formations. By integrating real-time NMR answer products into reservoir workflows, the MagniSphere service reduces uncertainty, improves well placement, and enhances reservoir understanding, supporting optimized drilling, completion, and production decisions directly at the wellsite.

• Carbonate and clastic reservoirs
  • Lithology-independent porosity, fluid typing, fluid mobility indicators, rock typing and facies analysis, pore-size characterization, and permeability indicators in complex pore systems
• Low-resistivity pay and thin-bed reservoirs
  • Direct pore-fluid measurements enable identification and evaluation of producible intervals in low-resistivity and thin-bed reservoirs where resistivity-based interpretation is uncertain
• Long horizontal wells
  • Real-time NMR measurements support geosteering, landing optimization, and water and tarmat avoidance
• Heavy oil and transition zones
  • Identification of viscous hydrocarbons and differentiation between movable and immobile fluids
• Grain-size distribution for completion design
  • Supports completion selection and optimization based on grain-scale characterization
• Saturation height functions for production optimization
  • Enables saturation height modeling using high-resolution porosity T₁ and T₂ distributions

• Improved reservoir understanding
  • Direct pore-fluid measurements reduce uncertainty in porosity, permeability, and fluid typing
• Real-time decision making
  • High-definition NMR data delivered while drilling enables faster and more confident operational decisions
• Lithology-independent measurements
  • Porosity and fluid volumes are unaffected by shale content or mineralogy
• Enhanced well placement
  • Early identification of producible intervals minimizes water production risk and improves lateral placement
• Sourceless reservoir evaluation solution
  • Enables reservoir evaluation in environments where the use of chemical radioactive sources is restricted

• Simultaneous T₁ and T₂ NMR acquisition while drilling for enhanced pore and fluid characterization
• High-definition NMR relaxation maps and distributions enabling detailed pore-size and fluid differentiation
• Lithology-independent pore-fluid measurements unaffected by shale content or mineralogy
• Real-time delivery of NMR answer products including porosity, fluid volumes, and permeability indicators
• Stable, high-quality NMR measurements under dynamic drilling conditions and long laterals
