Large-volume rotary sidewall coring service
Close the gap between continuous core and sidewall cores.
Core analysis: The more material, the better
The large-volume rotary sidewall coring service closes the gap between core plugs from continuous conventional core and wireline-conveyed rotary sidewall cores by retrieving up to fifty 1.5-in-OD by 2.5-in-long sidewall core samples in a single descent.
These large-volume core samples deliver a rock volume equivalent to conventional core plugs, matching the industry's standard sample size for routine core analysis (RCAL) and most special core analysis (SCAL) measurements with delivery in less time and at lower cost than conventional coring.
Three times the volume
At more than 3 times the rock volume of standard 0.92-in-diameter sidewall cores, the service's sidewall core samples recover a sufficient volume of rock to extract three triaxial minicores for full analysis of completion quality, which previously required conventional coring.
How it works
At each core point, the tool is anchored and the diamond coring bit assembly rotated from its transport position in the tool body to drill into the formation.
Once the full length of the coring bit assembly has drilled into the formation, the assembly is canted upward to sever the end of the core, which is retained in the core bit by the core catcher ring as the assembly is retracted into the tool.
Core markers separate each sidewall core sample stored in the tool for delivery to surface.
Large-volume rotary sidewall coring service
Close the gap between continuous core and sidewall cores.
Expanded functionality and safety for reliable recovery
New, rugged electronics provide additional capabilities in retrieving the larger rock samples. Compatibility with the latest telemetry systems accesses features previously reserved for sophisticated logging toolstrings. Physical drilling parameters, such as weight on bit, are under real-time control to ensure that the service is coring at the optimal settings for every core point.
Operational risk is greatly reduced. Not only is it the shortest rotary sidewall coring tool in the market today, at only 37 ft in length, but the shaft attached to the core bit has a special built-in safety feature to enable controlled release of the core bit if the bit becomes stuck in the formation. Compatibility with the electrically controlled release device (ECRD) also greatly increases the amount of pull allowed on the wireline cable, further reducing the chance of a stuck tool.
The large-volume rotary sidewall coring service recovers a sufficient volume of rock to extract three triaxial minicores for full analysis of completion quality, which previously required samples taken from conventional core.
