Enhance production management with real-time fiber-optic reservoir surveillance

Improve recovery by rapidly identifying—and responding to—changes in reservoir flow from distributed temperature sensing (DTS) using the WellWatcher BriteBlue multimode DTS fiber in applications up to 347 degF [175 degC].

Our fiber-optic technology enables you to monitor downhole distributed temperature profiles at the surface in real time. You can also transmit the data to your digital oilfield platform or other locations via satellite, Internet, or cable, so you can immediately identify the time, location, and reasons for changes in flow.

The result: Reduced downtime and deferred production because you can react more quickly to detrimental events, and cost savings because you can precisely identify the problem.

Simplify fiber delivery and economics

The optical fiber can be pumped through a conduit using Schlumberger patented techniques to provide a cost-effective DTS system suitable for high-volume applications. The conduit is hung from the surface across the interval of interest, and the temperature of the entire wellbore is monitored.

Downhole distributed temperature profiles can be monitored at the surface in real time; data can also be transmitted to multiple remote locations. Consequently, anomalies such as loss of tubing, casing, or cement integrity or malfunctioning gas lift valves can be immediately recognized and remedial actions planned.

Enhance lifetime in hydrogen environments

Conventional DTS-fiber temperature ratings do not take into account the degradation of the fiber when it is exposed to high levels of hydrogen (e.g., in SAGD wells), especially at high temperatures. Schlumberger pioneered accelerated aging tests for optical fibers at high temperatures. The fiber resulting from this research demonstrated an almost 50-fold increase in light transmission, exceptional resistance to hydrogen, longer life, faster response times, and better spatial resolution.
